Piezo, 1200-1 mbar, DN16KF, electrical connection Phoenix screw terminals, inverted switching logic
Piezo, 1200-1 mbar, DN16KF, electrical connection Phoenix screw terminals, inverted switching logic
The electronic vacuum switch VRCI with inverted switching logic functions as safty switch or for direct switching of pumps or valves in rough vacuum. Due to the additional output of a measuring signal, a process can be monitored without any problems.
Product code: VRCIShipping and Payment
383 EUR excl. VAT 463,43 EUR incl. VAT
The electronic vacuum switch VRCI with inverted switching logic functions as safty switch or for direct switching of pumps or valves in rough vacuum. Due to the additional output of a measuring signal, a process can be monitored without any problems.
Product code: VRCIShipping and Payment
Parameters
Measurement principles | Piezo |
---|---|
Gas dependency | independent of gas type (Piezo) |
Accuracy | 0.3 f.s. |
Response time | < 20 ms |
Materials in contact with vacuum | Stainless steel, 1.4305, Al₂O₃, ceramic, FKM |
Operating temperature | 0…+40°C |
Storage temperature | -10…+60 °C |
Voltage supply | 18 – 30 VDC |
Electrical connection | Phoenix screw terminals |
Article Number (choice of vacuum connection) | stainless steel small flange DN 16 ISO-KF with G1/4- female thread |
Protection class | IP54 |
Weight (kg) | Approx. 450 g |
Category | Vacuum switch |
Download
VRC (1).step (step, 688.9 kB)
man_vrci.pdf (pdf, 1.4 MB)
VRC-vacuum-switch-Piezo-en (1).pdf (pdf, 1.7 MB)
